Home > products > FPV Drone Kit > LOONG F2-10 Hexacopter Drone with 80 Min Flight Time

LOONG F2-10 Hexacopter Drone with 80 Min Flight Time

Product Details

Brand Name: MMC

Certification: ROHS

Model Number: Fiber Optic Combat UAV LOONG F2-10

Document: LOONG F2-10 Over-the-horizo...em.pdf

Payment & Shipping Terms

Minimum Order Quantity: 2

Price: Negotiable

Delivery Time: 30

Payment Terms: T/T

Supply Ability: 20000pcs/Mouth

Get Best Price
Product Details
Highlight:

FPV drone kit for aerial surveying

,

20km range FPV drone

,

15kg payload drone kit

Interference:
100A/m(industrial Magnetic Field)
Mapping Distance:
20km
Automatic Obstacleavoidance:
360° Omnidirectionalobstacle Avoidance (horizontal)
Police PrivateNetwork (optional):
The UAV Is Equipped With A Function Module For Accessing The Private Network (police Unmanned Aerial Vehicle Frequency Band). It Supports Real-time Control Of The UAV And Its Mounting And Real-time Video Transmission Back To The Backstage Command Center Un
Expand Max. Size:
2190*2415*560mm (With Paddle)
Max. Load:
15kg
Working Temperature:
-20°C-60℃
4G/5G Communicatio(optional):
Equipped With 4G And 5G Link Function, Realizing Public Network Link To Control The UAV And Its Mount, Return Real-time Video To The Backstage Command Center, And Be Able To Synchronize The Health Status Of The Avionics System In Real Time To The Cloud And
Interference:
100A/m(industrial Magnetic Field)
Mapping Distance:
20km
Automatic Obstacleavoidance:
360° Omnidirectionalobstacle Avoidance (horizontal)
Police PrivateNetwork (optional):
The UAV Is Equipped With A Function Module For Accessing The Private Network (police Unmanned Aerial Vehicle Frequency Band). It Supports Real-time Control Of The UAV And Its Mounting And Real-time Video Transmission Back To The Backstage Command Center Un
Expand Max. Size:
2190*2415*560mm (With Paddle)
Max. Load:
15kg
Working Temperature:
-20°C-60℃
4G/5G Communicatio(optional):
Equipped With 4G And 5G Link Function, Realizing Public Network Link To Control The UAV And Its Mount, Return Real-time Video To The Backstage Command Center, And Be Able To Synchronize The Health Status Of The Avionics System In Real Time To The Cloud And
Product Description
Drone LOONG F2-10
  • Material: X Carbon Fiber, Aluminum Alloy, Engineering Plastics
  • Wheelbase: 706 mm
  • Expand max.size: 480*609*208mm (Without paddle)
  • Expand max.size:966*836*208mm (With paddles)
  • Fuselage weigh: 2.8kg(Excluding battery and mount)
  • Unladen weight: 3.8kg
  • Standard weight: 2.5kg
  • Max.load:5kg
  • Endurance:50min@no load, 35min@1kg
  • 20min@2.5kg,8min@5kg
  • Working temperature: -20°C~60°C
  • Working humidity: 10%~90% non-condensing
  • Protection class: lP54
  • Electromagnetic interference: 100A/m (Industrial Frequency Magnetic Field)
  • Elevation gain:5000m
  • Max. flight speed: 25m/s
  • Battery:14000mAh*1
Remote control
  • Screen: 5.5 inches
  • Storage: ROM 16GB + expandable (up to 128G)
  • Video output interface: HDMI
  • Built-in battery: Lithium-ion(4800mAh-7.2V)
  • Charging mode: support 12V/9V/5V
  • Working ambient temperature: -10~60°C
  • Charging time: 2.5h (using a 9V USB charger)
  • Charging ambient temperature: 0-40°C
  • Rating: 20W
  • Endurance: 4h
FPV glasses
  • Screen resolution: 720P/1080P
  • Support customization
  • Screen material: LCD
  • Power input: 7-26V(2-6s)
  • Video input interface: micro-HDMI
Chargers
  • Specification: dual 6s charger, input AC 100V-240V,AC 200W
  • Use of working temperature: 0~40°C
  • Dimension: 135*105*68mm
  • Weight: 580g
Flight battery
  • Battery string number: 6s
  • Full charge voltage: 25.8V
  • Nominal voltage: 20.88V
  • Minimum voltage: 15.6V
  • Nominal capacity: 13.8Ah
  • Typical capacity: 14.3Ah
  • Standard charge: 7A
  • Standard discharge: 42A
  • Instantaneous discharge: 98A
  • Weight: 942g±10g
